Eyeball Jet Nozzle Diffuser FK043

Genernal Description

Eyeball jet nozzle diffusers are an excellent choice for applications that require a lot of air and take directional and/or focused shots. Ideal for theatres, shopping centres, auditoriums, gyms and industrial applications. The core is manually adjustable, which ensures that air can be directed anywhere. Radial dampers available.

Major Advantage Highlights

1. 45° in all direction

2. 360° rotation

3. Duct or hard surface mountable

4. Optional aperture volume damper accessible on face of nozzle

Free Consultation

Performance / Characters

Material

Aluminum

Surface Finish

Electrostatic spraying, anodizing

Color Options

RAL9016 or RAL9010 white powder coating as standard

Instructions

The adjustment is flexible, the head can be rotated, and the rotation range is wide

Detailed Pictures

Structure Diagram

Front

Reverse

Side

Hardwares & Accessories

1. Dimension Limits

Specification	41	75	108	140	165	190	220	265
ØA	83	144	208	245	308	343	395	490
ØD	120	194	260	299	368	415	470	580
ØL	65	112	165	180	248	270	320	365
Mounting Distance ØB	100	174	240	280	348	392.5	440	556
